LC1K0910E7 - TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 48 V AC coil, Schneider Electric
- Product Code: LC1K0910E7
- Brand: Schneider Electric
- Availability: To be confirmed
- € 20.66 Ex Tax:
MAIN CHARACTERISTICS
range of product
TESYS K
range
TESYS
product or component type
CONTACTOR
product name
TESYS K
device short name
LC1K
device application
CONTROL
contactor application
MOTOR CONTROL
COMPLEMETARY CHARACTERISTICS
utilisation category
AC-1
poles description
3P
power pole contact composition
3 NO
[Ie] rated operational current
20 A <= 50 C AT <= 440 V AC AC-1 FOR POWER CIRCUIT
control circuit type
AC 5060 HZ
[Uc] control circuit voltage
48 V AC 5060 HZ
motor power kW
2.2 KW AT 220...230 V AC 5060 HZ AC-3
auxiliary contact composition
1 NO
overvoltage category
III
[Ith] conventional free air thermal current
20 A AT <= 50 C FOR POWER CIRCUIT
Irms rated making capacity
110 A AC FOR POWER CIRCUIT CONFORMING TO NF C 63-110
rated breaking capacity
110 A AT 415 V CONFORMING TO IEC 60947
associated fuse rating
25 A GG AT <= 440 V FOR POWER CIRCUIT
average impedance
3 MOHM AT 50 HZ - ITH 20 A FOR POWER CIRCUIT
insulation resistance
> 10 MOHM FOR SIGNALLING CIRCUIT
inrush power in VA
30 VA AT 20 DC
hold-in power consumption in VA
4.5 VA AT 20 DC
heat dissipation
1.3 W
control circuit voltage limits
0.8...1.15 UC AT <= 50 C OPERATIONAL
operating rate
3600 CYCH
auxiliary contacts type
TYPE INSTANTANEOUS 1 NO
signalling circuit frequency
<= 400 HZ
minimum switching current
5 MA FOR SIGNALLING CIRCUIT
minimum switching voltage
17 V FOR SIGNALLING CIRCUIT
operating time
10...20 MS COIL DE-ENERGISATION AND NO OPENING
safety reliability level
B10D = 1369863 CYCLES CONTACTOR WITH NOMINAL LOAD CONFORMING TO ENISO 13849-1
non overlap distance
0.5 MM
mechanical robustness
SHOCKS CONTACTOR CLOSED ON X AXIS 10 GN FOR 11 MS IEC 60068-2-27
compatibility code
LC1K
