NSYSDT5 - Folding support tray - 500 mm enclosure - 30 kg load, Schneider Electric
- Product Code: NSYSDT5
- Brand: Schneider Electric
- Availability: To be confirmed
- € 113.24 Ex Tax:
MAIN CHARACTERISTICS
range
SPACIAL
product or component type
FOLDING SUPPORT TRAY
Application
MULTI-PURPOSE
For enclosure nominal dimensions
W 500 MM
mounting location
ON DOOR REINFORCEMENT FRAME
mounting support
CROSS RAILS
range compatibility
SPACIAL SF SM SFX SMX S3D CRN ENCLOSURES
device composition
FIXING ELEMENTS
quantity per set
SET OF 1
COMPLEMETARY CHARACTERISTICS
material
STEEL
colour
GREY RAL 7035
surface finish
EPOXY-POLYESTER POWDER
fixing mode
BY FIXING ELEMENT
adjustment
ADJUSTABLE IN HEIGHT STEPS OF 25 MM
operating angle
45
maximum load
30 KG M
height
50 MM
width
nominal : 500 mm
depth
350 MM
thickness
1.5 MM
