STBNFP2212 - standard Network Interface Module STB - Fipio - 1 Mbit/s, Schneider Electric
- Product Code: STBNFP2212
- Brand: Schneider Electric
- Availability: To be confirmed
- € 365.41 Ex Tax:
MAIN CHARACTERISTICS
range of product
MODICON STB DIST I O SOLUTION
product or component type
STD NETWORK INTERFACE MODULE
integrated connection type
FIPIO CONFORMING TO EN 50170 VOL3 PART 1-3 2-3 3-3 5-3 6-37-3 9-WAY MALE SUB-D CONNECTOR 1 TWISTED SHIELDED PAIR BUS
number of segments
1 PRIMARY MAX 6 EXTENSIONS
number of devices per segment
0...128 ALL SEGMENT
transmission rate
1 MBITS FOR BUS LENGTH OF 0...1000 M PER SEGMENT
structure type
OPEN INDUSTRIAL FIELDBUS
COMPLEMETARY CHARACTERISTICS
number of addressable I/O module
0..32 PER ISLAND
communication service
FDR
[Us] rated supply voltage
24 V DC
power supply type
SELV
supply current
>= 700 MA
supply voltage limits
19.2...30 V
input current
430 MA FOR SUPPLY CIRCUIT
nominal output current
0.575 A 60...70 DC
output voltage
5.25 V DC TOLERANCE +- 0.21 FOR LOGIC BUS
marking
CE
overvoltage category
II
status LED
1 LED GREEN FOR FIPRUN
depth
70 MM
height
40 MM
width
128.3 MM
product weight
0.145 KG
