TM2DMM8DRT - discrete I/O module M238 - 4 inputs 24 V DC - 4 outputs relay- 1 terminal block, Schneider Electric
- Product Code: TM2DMM8DRT
- Brand: Schneider Electric
- Availability: To be confirmed
- On Request Ex Tax:
MAIN CHARACTERISTICS
range of product
MODICON M238 LOGIC CONTROLLER
product or component type
DISCRETE I O MODULE
discrete input number
4
discrete input voltage
24 V
discrete input voltage type
DC
discrete output number
4
discrete output type
RELAY
COMPLEMETARY CHARACTERISTICS
range compatibility
ADVANTYS OTB
input voltage limits
20.4..28.8 V
discrete input logic
SINK OR SOURCE
discrete input current
7 MA
input impedance
3.4 KOHM
discrete output function
1 NO
current per channel
2 A
current per output common
7 A
number of common point
1 FOR INPUT
contact resistance
<= 45 MOHM
response time
<= 10 MS FROM STATE 0 TO STATE 1 OUTPUT
minimum switching current
0.1 MA 0.1 V DC
isolation between channels
NONE
isolation between channels and internal logic
2300 V FOR 1 MINUTE OUTPUT
isolation between input channel and output channel
1500 V FOR 1 MINUTE
isolation between output channels group
1500 V FOR 1 MINUTE
mechanical durability
20000000 CYCLES
electrical durability
100000 CYCLES 0.5 A AC-15 240 V AC COS PHI = 0.35 INDUCTIVE
current consumption
20 MA 24 V DC AT STATE 1 FOR ALL INPUTOUTPUT
local signalling
1 DISPLAY BLOCK
electrical connection
1 REMOVABLE SCREW TERMINAL BLOCK
mounting support
35 MM SYMMETRICAL DIN RAIL
product weight
0.095 KG
