9001SKP38G9 - octagonal pilot light Ø 30 - green - incandescent BA 9s - 120V AC/DC - IP66, Schneider Electric
- Product Code: 9001SKP38G9
- Brand: Schneider Electric
- Availability: To be confirmed
- On Request Ex Tax:
MAIN CHARACTERISTICS
range of product
HARMONY 9001SK
product or component type
PILOT LIGHT
device short name
9001SK
lens type
DOMED PLASTIC
light block supply
DIRECT
COMPLEMETARY CHARACTERISTICS
bezel material
PLASTIC
mounting diameter
30 MM
shape of signaling unit head
ROUND
cap/operator or lens colour
GREEN
light source
INCANDESCENT
bulb base
BA 9S
[Us] rated supply voltage
120 V ACDC
tightening torque
0.8 N.M CONFORMING TO ENIEC 6
shape of screw head
CROSS SLOTTED HEAD
connections - terminals
SCREW CLAMP TERMINALS 1 X 0.2
[Ith] conventional free air thermal current
10 A
short-circuit protection
10 A CARTRIDGE FUSE CONFORMING TO ENIEC 60947-5-1
[Ui] rated insulation voltage
250 V DEGREE OF POLLUTION 2 CONFORMING TO ENIEC 60947-1
[Uimp] rated impulse withstand voltage
2.5 KV CONFORMING TO ENIEC 60
operating position
ANY POSITION
CAD overall width
54 MM
CAD overall height
70 MM
CAD overall depth
42 MM
product weight
0.082 KG
device presentation
COMPLETE PRODUCT
compatibility code
9001SK
