GB2CD10 - TeSys GB2 - thermal-magnetic circuit breaker - 1P + N - 5 A - Id = 66 A , Schneider Electric
- Product Code: GB2CD10
- Brand: Schneider Electric
- Availability: To be confirmed
- € 18.38 Ex Tax:
MAIN CHARACTERISTICS
range
TESYS
product name
TESYS GB2
device short name
GB2
product or component type
CIRCUIT BREAKER
device application
CONTROL
poles description
1P+N
network type
AC DC
utilisation category
CATEGORY A CONFORMING TO IEC 60947-2
network frequency
5060 HZ CONFORMING TO IEC 60947-2
breaking capacity
ICU = 1 KA AT 48 V DC CONFORMING TO IEC 60947-2
[Ics] rated service short-circuit breaking capacity
75 AT 110 V AC 5060 HZ CONFORMING TO IEC 60947-2
trip unit technology
THERMAL-MAGNETIC
magnetic tripping current
66 A
COMPLEMETARY CHARACTERISTICS
mounting mode
BY CLIPS
mounting support
PLATE
mounting position
HORIZONTAL
control type
TOGGLE
[In] rated current
5 A
[Ue] rated operational voltage
250 V AC 5060 HZ CONFORMING TO IEC 60947-2
[Uimp] rated impulse withstand voltage
4 KV CONFORMING TO IEC 60947-2
power dissipation per pole
2 W
mechanical durability
8000 CYCLES
electrical durability
8000 CYCLES
connections - terminals
CONNECTOR 1 CABLES 0.75...6 MM - CABLE STIFFNESS SOLID - WITHOUT CABLE END
tightening torque
1.2 N.M - ON CONNECTOR
mechanical robustness
SHOCKS 22 GN FOR 20 MS CONFORMING TO IEC 60068-2-27
quantity per set
SET OF 6
9 mm pitches
2
height
74 MM
width
15 MM
depth
67 MM
product weight
0.07 KG
compatibility code
GB2
