GVAED101 - TeSys GV3 - auxiliary contact block - 2 NO, Schneider Electric
- Product Code: GVAED101
- Brand: Schneider Electric
- Availability: To be confirmed
- € 6.42 Ex Tax:
MAIN CHARACTERISTICS
range of product
TESYS GV3
range
TESYS
device short name
GVAED
product or component type
AUXILIARY CONTACT BLOCK
product compatibility
GV3L
auxiliary contacts operation
FAULT SIGNAL 1 NO
pole contact composition
2 NO
connections - terminals
SCREW CLAMP TERMINALS 1 CABLE 1...2.5 MM - CABLE STIFFNESS SOLID
COMPLEMETARY CHARACTERISTICS
mounting location
FRONT SIDE
[Ui] rated insulation voltage
600 V - CONFORMING TO UL 508
[Ue] rated operational voltage
24..240 V AC
[Ith] conventional free air thermal current
2.5 A
protection type
GB2CB... CIRCUIT BREAKER RATING ACCORDING TO OPERATIONAL CURRENT FOR UE <= 415 V
mechanical durability
100000 CYCLES
minimum switching current
5 MA
minimum switching voltage
17 V
rated operational power in VA
300 VA AT 48 V AC-15 - ELECTRICAL DURABILITY 100000 CYCLES
rated operational power in W
120 W AT 240 V DC-13 - ELECTRICAL DURABILITY 100000 CYCLES
tightening torque
<= 1.4 N.M - ON SCREW CLAMP TERMINALS
height
89 MM
width
9.3 MM
depth
66 MM
product weight
0.05 KG
compatibility code
GVAED
