LADN223G - TeSys D - auxiliary contact block - 2 NO + 2 NC - spring terminals - EN 50012, Schneider Electric
- Product Code: LADN223G
- Brand: Schneider Electric
- Availability: To be confirmed
- € 27.62 Ex Tax:
MAIN CHARACTERISTICS
range of product
TESYS D
range
TESYS
device short name
LADN
product or component type
AUXILIARY CONTACT BLOCK
product compatibility
LC1DT20..DT40
range compatibility
TESYS D LC1D CONTACTOR
auxiliary contacts operation
INSTANTANEOUS
pole contact composition
2 NO + 2 NC
Shielding continuity terminal
WITHOUT
connections - terminals
SPRING TERMINALS 2 CABLE 2.5 MM - CABLE STIFFNESS FLEXIBLE - WITHOUT CABLE END
COMPLEMETARY CHARACTERISTICS
mounting location
FRONT
[Ui] rated insulation voltage
600 V - CERTIFICATIONS UL
[Ue] rated operational voltage
690 V AC 25..400 HZ
[Ith] conventional free air thermal current
10 A AT <= 60 DC
Irms rated making capacity
140 A AC CONFORMING TO IEC 60947-5-1
permissible short-time rating
100 A AT 60 C 1 S
protection type
GG FUSE <= 10 A RATING ACCORDING TO OPERATIONAL CURRENT FOR UE <= 690 V
associated fuse rating
10 A gG IEC 60947-5-1
mechanical durability
3 MCYCLES
minimum switching current
5 MA
minimum switching voltage
17 V
non-overlap time
1.5 MS ON DE-ENERGISATION NO OVERLAP BETWEEN NC AND NO CONTACT
overlap time
1.5 MS
insulation resistance
> 10 MOHM
