SSL1A12BDR - solid state relay Plug-in input 15-30 V DC output 24-280 V AC 2A, Schneider Electric
- Product Code: SSL1A12BDR
- Brand: Schneider Electric
- Availability: To be confirmed
- € 8.79 Ex Tax:
MAIN CHARACTERISTICS
range of product
ZELIO RELAY
product or component type
SOLID STATE RELAY
device short name
SSL
network number of phases
1 PHASE
COMPLEMETARY CHARACTERISTICS
mounting support
SOCKET
[In] rated current
2 A
output voltage
24..280 V AC
[Uc] control circuit voltage
15...30 V DC
contacts type and configuration
1 NO
capacitance unbalance
<= 1.5 pF input/output
minimum switching voltage
15 V DC TURN-ON
maximum switching voltage
10 V DC TURN-OFF
input current limits
6 MA
input impedance
3500 OHM
solid state output type
SCR OUTPUT
load current
0.07...2 A
absolute maximum voltage
600 V
surge current
<= 120 A for 16.6 ms
voltage drop
<= 1.1 V on-state
maximum I²t for fusing
285 A².s for 10 ms at 50 Hz half cycle
leakage current
<= 4 mA off-state
dV/dt
500 VS OFF-STATE AT MAXIMUM VOLTAGE
response time
0.5 CYCLE TURN-OFF
overvoltage category
III
width
5 MM
height
28 MM
depth
15 MM
product weight
0.0041 KG
device presentation
COMPLETE PRODUCT
