VN20 - TeSys Mini-VARIO - Switch body for switch-disconnector - 3 poles - 20 A, Schneider Electric
- Product Code: VN20
- Brand: Schneider Electric
- Availability: To be confirmed
- € 7.25 Ex Tax:
MAIN CHARACTERISTICS
range
TESYS
product name
TESYS MINI VARIO
device short name
VN
product or component type
SWITCH BODY
performance level
STANDARD
poles description
3P
contacts type and composition
3 NO
network type
AC
network frequency
50 60 HZ
COMPLEMETARY CHARACTERISTICS
mounting support
SYMMETRICAL RAIL
[Ue] rated operational voltage
690 V AC 5060 HZ
[Uimp] rated impulse withstand voltage
6 KV
[Ith] conventional free air thermal current
20 A
[Ithe] conventional enclosed thermal current
16 A
[Ie] rated operational current
11 A (AC-23) at 400 V
rated operational power in W
11 kW at 690 V (AC-23A)
intermittent duty class
30
Making capacity ( I Rms)
200 A 400 V (AC-21A)
[Icm] rated short-circuit making capacity
0.5 kA 400 V at Ipeak
[Icw] rated short-time withstand Rms current
140 A 400 V during 1 s
rated conditional short-circuit current
6 kA 400 V - associated fuse 20 A aM
breaking capacity
200 A 400 V AC-21A
mechanical durability
50000 CYCLES
electrical durability
30000 cycles DC-1...5
suitability for isolation
YES
connections - terminals
power circuit : screw clamp terminals cable 4 mm² - cable stiffness: solid -
tightening torque
power circuit : 0.7 N.m - on screw clamp terminals
height
46.5 MM
width
56 MM
depth
62 MM
product weight
0.11 KG
compatibility code
V
