XVLA233 - pilot light Ø8 - IP40/IP65 - green - covered LED included - 24V - faston, Schneider Electric
- Product Code: XVLA233
- Brand: Schneider Electric
- Availability: To be confirmed
- € 4.42 Ex Tax:
MAIN CHARACTERISTICS
range of product
HARMONY XVL
product or component type
LED PL LIGHT W INTL LENS CAP
component name
XVL
mounting diameter
8 MM
light source
COVERED LED
light block colour
GREEN
protection type
INTEGRAL BALLAST RESISTOR
[Us] rated supply voltage
24 V
IP degree of protection
IP65 WITH SEAL XVLZ911 CONFORMING TO IEC 60529
COMPLEMETARY CHARACTERISTICS
supply circuit type
DC
connections - terminals
TAG FOR FASTON CONNECTORS 2.8 X 0.5 MM
current consumption
18 MA
[Ui] rated insulation voltage
50 V CONFORMING TO IEC 60947-1
bulb lifespan
>= 100000 H
nominal voltage limit
0.8..1.1 UN
terminals description ISO n°1
X1-X2PL
height
10 MM
width
10 MM
depth
36 MM
product weight
0.003 KG
