XVLA333 - pilot light Ø12 - IP40/IP65 - green - covered LED included - 24V - lugs, Schneider Electric
- Product Code: XVLA333
- Brand: Schneider Electric
- Availability: To be confirmed
- € 6.25 Ex Tax:
MAIN CHARACTERISTICS
range of product
HARMONY XVL
product or component type
LED PL LIGHT W INTL LENS CAP
component name
XVL
mounting diameter
12 MM
light source
COVERED LED
light block colour
GREEN
protection type
INTEGRAL BALLAST RESISTOR
[Us] rated supply voltage
24 V
IP degree of protection
IP65 WITH SEAL XVLZ912 CONFORMING TO IEC 60529
COMPLEMETARY CHARACTERISTICS
supply circuit type
DC
connections - terminals
THREADED CONNECTOR CLAMPING CAPACITY 1 X 0.2...1 X 1.5 MM
current consumption
18 MA
[Ui] rated insulation voltage
50 V CONFORMING TO IEC 60947-1
bulb lifespan
>= 100000 H
nominal voltage limit
0.8..1.1 UN
terminals description ISO n°1
X1-X2PL
height
16 MM
width
16 MM
depth
51 MM
product weight
0.007 KG
