ZBRN2 - access point - 2 RJ45-24..240V AC/DC-4 displays-5 LEDs-Modbus-wireless radio, Schneider Electric
- Product Code: ZBRN2
- Brand: Schneider Electric
- Availability: To be confirmed
- € 177.72 Ex Tax:
MAIN CHARACTERISTICS
range of product
HARMONY
product or component type
WIRELESS ACCESS POINT
device short name
ZBRN2
product specific application
INTERFACE TO PLC
function of module
MONOSTABLE
communication port protocol
Zigbee green power at 2.4 GHz conforming to IEEE 802.15.4
antenna type
INTEGRATED
frequency
2405 MHZ FOR RECEIVER
COMPLEMETARY CHARACTERISTICS
[Us] rated supply voltage
24...240 V ACDC AT 5060 HZ - 10...10
immunity to microbreaks
10 MS
maximum sensing distance
100 M IN FREE FIELD
response time
< 30 ms after transmitter clicks
channels utilisation
<= 60
power consumption in W
<= 4 W ACDC
breaking capacity
15 W
breaking capacity
750 VA
control circuit frequency
50..60 HZ + - 10 PT
short-circuit protection
16 A by GB2 circuit breaker
operating position
ANY POSITION WITHOUT DERATING
electrical connection
1 CONDUCTOR CABLE 0.2...4 MM AWG 24...AWG 12 SOLID WITHOUT CABLE END IEC 60947-1
tightening torque
0.35...0.4 N.m conforming to EN/IEC 60947-1
housing material
SELF-EXTINGUISHING PLASTIC
status LED
1 LED (green) : power ON
mounting support
35 MM SYMMETRICAL DIN RAIL CONFORMING TO ENIEC 60715
rated short-duration power frequency withstand voltage
1.5 kV at 50 Hz conforming to EN/IEC 60947-5-1
[Uimp] rated impulse withstand voltage
4 KV
surge withstand
1 KV DIFFERENTIAL MODE CONFORMING TO IEC 61000-4-5
width
122 MM
height
90 MM
depth
60 MM
product weight
0.27 KG
antenna gain
0 DBI
marking
CE
integrated connection type
1 isolated serial link (2 x RJ45 in parallel in Modbus Serial line slave) ,Modbus slave RTU asynchronous in baseband RS485 half duplex 1.2...115.2 kbauds 2 twisted shielded pairs
data storage equipment
SD CARD
topology
DVS LKD BY DSY-CNG OR TP JCTNS
data format
7 OR 8 BITS 1 OR 2 STOP BITS
parity
EVEN
