ZBV18M4 - red flashing light block for head Ø22 integral LED 240V screw clamp terminals, Schneider Electric
- Product Code: ZBV18M4
- Brand: Schneider Electric
- Availability: To be confirmed
- On Request Ex Tax:
MAIN CHARACTERISTICS
range of product
HARMONY XB4
product or component type
LIGHT BLOCK
device short name
ZBV
sale per indivisible quantity
5
connections - terminals
screw clamp terminals : <= 2 x 1.5 mm² with cable end conforming to EN 60947-1
signalling type
FLASHING
light source
PROTECTED LED
bulb base
INTEGRAL LED
light block supply
DIRECT
light source colour
RED
[Us] rated supply voltage
230..240 V AC 5060 HZ
COMPLEMETARY CHARACTERISTICS
product weight
0.017 KG
tightening torque
0.8...1.2 N.M CONFORMING TO EN 60947-1
shape of screw head
CROSS HEAD COMPATIBLE WITH PHILIPS NO 1 SCREWDRIVER
supply voltage limits
195..264 V AC
current consumption
14 MA
service life
100000 H AT RATED VOLTAGE AND 25 C
surge withstand
1 KV CONFORMING TO IEC 61000-4-5
mounting of block
FRONT MOUNTING
electrical composition code
M1
compatibility code
ZBV
