ZB5AD8 - black selector switch head Ø22 3-position spring return, Schneider Electric
- Product Code: ZB5AD8
- Brand: Schneider Electric
- Availability: To be confirmed
- € 5.44 Ex Tax:
MAIN CHARACTERISTICS
range of product
HARMONY XB5
product or component type
HEAD FOR SELECTOR SWITCH
device short name
ZB5
bezel material
PLASTIC
mounting diameter
22 MM
sale per indivisible quantity
1
shape of signaling unit head
ROUND
type of operator
SPRING RETURN RIGHT TO CENTRE
operator profile
BLACK STANDARD HANDLE
operator position information
3 POSITIONS + - 45 D
COMPLEMETARY CHARACTERISTICS
CAD overall width
29 MM
CAD overall height
29 MM
CAD overall depth
46 MM
product weight
0.017 KG
mechanical durability
1000000 CYCLES
main group
SELECTOR SWITCH
group of product
NON ILLUMINATED
station name
XALD 1..5 CUT-OUTS
cap/operator or lens colour
BLACK
electrical composition code
C3 FOR <= 6 CONTACTS USING SINGLE BLOCKS IN FRONT MOUNTING
compatibility code
ZB5
The Schneider Electric ZB5AD8 is a reliable, high-quality industrial component available through electric-shops.com, part of the global electric shops network. Enjoy fast delivery, competitive pricing, and professional support from a trusted global distributor.
