A9N61701 - C120NA-DC - 2P - 100 A - 1000 V, Schneider Electric
- Product Code: A9N61701
- Brand: Schneider Electric
- Availability: To be confirmed
- € 113.18 Ex Tax:
MAIN CHARACTERISTICS
switch application
PHOTOVOLTAIC PV ARRAY
range
ACTI 9
range of product
C120
product or component type
SWITCH DISCONNECTOR
product name
C120
device short name
C120NA-DC
poles description
2P
utilisation category
DC-21B
suitability for isolation
YES ENIEC 60947-3
COMPLEMETARY CHARACTERISTICS
[Ie] rated operational current
100 A DC-21B 1000 V DC
[Ui] rated insulation voltage
1000 V DC
[Uimp] rated impulse withstand voltage
6 KV
control type
TOGGLE
local signalling
ON OFF INDICATION
mounting mode
CLIP-ON
mounting support
DIN RAIL
connection pitch
NO RENDITION
9 mm pitches
12
height
138.3 MM
width
108 MM
depth
74.4 MM
product weight
0.96 KG
colour
WHITE
mechanical durability
20000 CYCLES
electrical durability
300 cycles
connections - terminals
PRE-WIRED CABLE DOWNSIDE
wire stripping length
15 MM
tightening torque
3.5 N.M
compatibility code
C120NA-DC
