ABR7S11 - plug-in electromechanical relay - 5 mm - 24 V DC - 1 NO, Schneider Electric
- Product Code: ABR7S11
- Brand: Schneider Electric
- Availability: To be confirmed
- € 4.87 Ex Tax:
MAIN CHARACTERISTICS
range of product
ADVANTYS TELEFAST ABE7
product or component type
PLUG-IN ELECTROMECH RELAY
control circuit type
DC
quantity per set
SET OF 4
COMPLEMETARY CHARACTERISTICS
width pitch dimension
5 MM
product compatibility
ABE7P16M111
[Uc] control circuit voltage
24 V
[Ith] conventional free air thermal current
6 A
contacts type and composition
1 NO
threshold tripping voltage
16.8 V AT 40 DC
drop-out voltage
2 V AT 20 DC
drop-out current
0.5 MA AT 20 DC
power dissipation per pole
<= 0.17 W
associated fuse rating
1 A FAST BLOW
maximum switching voltage
250 V AC 5060 HZ CONFORMING TO IEC 60947-5-1
electrical durability
500000 CYCLES MAXIMUM SWITCHING CURRENT 2000 MA AT 230 V AC-12
minimum switching current
100 MA AT >= 5 V
operating rate in Hz
20 HZ NO LOAD
mechanical durability
20000000 CYCLES
[Uimp] rated impulse withstand voltage
6 KV CONFORMING TO IEC 60947-1
product weight
0.005 KG
The Schneider Electric ABR7S11 is a reliable, high-quality industrial component available through electric-shops.com, part of the global electric shops network. Enjoy fast delivery, competitive pricing, and professional support from a trusted global distributor.
