ABR7S23 - plug-in electromechanical relay - 10 mm - 24 V DC - 1 CO, Schneider Electric
- Product Code: ABR7S23
- Brand: Schneider Electric
- Availability: To be confirmed
- € 4.83 Ex Tax:
MAIN CHARACTERISTICS
range of product
ADVANTYS TELEFAST ABE7
product or component type
PLUG-IN ELECTROMECH RELAY
control circuit type
DC
quantity per set
SET OF 4
COMPLEMETARY CHARACTERISTICS
width pitch dimension
10 MM
product compatibility
ABE7P16T210
[Uc] control circuit voltage
24 V
[Ith] conventional free air thermal current
5 A
contacts type and composition
1 CO
threshold tripping voltage
19.7 V AT 40 DC
drop-out voltage
2.4 V AT 20 DC
drop-out current
1 MA AT 20 DC
power dissipation per pole
<= 0.36 W
associated fuse rating
1 A FAST BLOW
maximum switching voltage
130 V DC CONFORMING TO IEC 60947-5-1
electrical durability
500000 CYCLES MAXIMUM SWITCHING CURRENT 1200 MA AT 230 V AC-12
minimum switching current
10 MA AT >= 5 V
electrical reliability
0.00000001
operating rate in Hz
10 HZ NO LOAD
mechanical durability
20000000 CYCLES
[Uimp] rated impulse withstand voltage
2.5 KV CONFORMING TO IEC 60947-1
product weight
0.008 KG
