KBB25ED4303TW - Canalis - straight length -25A- 3m - 1 circuit - 3L+N+PE -DALI compatible-white, Schneider Electric
- Product Code: KBB25ED4303TW
- Brand: Schneider Electric
- Availability: To be confirmed
- € 104.76 Ex Tax:
MAIN CHARACTERISTICS
range
CANALIS
range of product
CANALIS
product or component type
BUSBAR TRUNKING
device short name
KBB
product compatibility
KBB
COMPLEMETARY CHARACTERISTICS
device application
LIGHTING
radiated magnetic field
2 PT
[Ue] rated operational voltage
230..400 V
[Uimp] rated impulse withstand voltage
4 KV
[Ui] rated insulation voltage
690 V
[Ie] rated operational current
25 A AT 35 DC
network frequency
50 60 HZ
[Icw] rated short-time withstand current
0.44 KA
[Ipk] rated peak withstand current
4.4 KA
thermal stress limit
195 KA.S
THDI
25 A AT 0...15
voltage drop
0.72 V WITH POWER FACTOR = 1 AT 50 HZ WITH 1A FOR 100 M LONG
linear resistance
R20= 6.8 mΩ/m for 20 °C-phase conductor
mounting mode
BY SCREWS
busbar description
STRAIGHT LENGTH
busbar trunking polarity
3L+N+PE
number of circuits
1
number of tap-off outlets
3
control type
COMMUNICATING
standards
EN IEC 60439 2
width
3100 MM
depth
51 MM
height
60 MM
length
3 M
colour
RAL 9003 WHITE
product weight
2.6 KG
quantity per set
SET OF 6
