ZBE5023 - single contact block for head Ø22 1NC Faston connector, Schneider Electric
- Product Code: ZBE5023
- Brand: Schneider Electric
- Availability: To be confirmed
- € 3.23 Ex Tax:
MAIN CHARACTERISTICS
range of product
HARMONY XB4
product or component type
CONTACT BLOCK
device short name
ZBE
sale per indivisible quantity
1
IP degree of protection
IP20 IEC 60529
contacts type and composition
1 NC
contact operation
SLOW-BREAK
contact block type
SINGLE
contacts usage
HIGH POWER SWITCHING CONTACTS
connections - terminals
FASTON CONNECTOR 1 X 6.35 MM
COMPLEMETARY CHARACTERISTICS
product weight
0.02 KG
positive opening
WITH
mechanical durability
10000000 CYCLES
short-circuit protection
10 A CARTRIDGE FUSE GG ENIEC 60947-5-1
[Ith] conventional free air thermal current
10 A ENIEC 60947-5-1
[Ui] rated insulation voltage
300 V EN 60947-1
[Uimp] rated impulse withstand voltage
6 KV EN 60947-1
[Ie] rated operational current
1.1 A 125 V DC-13 P300 ENIEC 60947-5-1
mounting of block
FRONT MOUNTING
condition of use
MOUNTING ON PUSH-BUTTON COLLAR
electrical composition code
C15 1
compatibility code
ZBE
